36" 400 CFM Range Hood with LED Task Lighting
Dimensions
Width: 36
Height: 21
Depth: 19.68
Color
Stainless Steel
Features
3-speed, 300 CFM motor class (Performance varies based on installation. Resources available at aham.org.)
- Three fan speeds provide the right amount of ventilation for every meal you prepare.
- Bright, long-lasting LED task lighting makes it easy to see what you're cooking.
- Help trap unwanted grease and remove odors with a filter that unlatches from the hood so you can wash it with soap and water at the sink.
- A convertible design allows for installation that can be vented externally or internally. When internal venting, recirculation passes the air through charcoal filters (sold separately) to trap grease and odors before pushing the air back into the home.
- This hood is equipped to handle the high heat and cooking power of cooktops up to 44.5K BTUs.
- This hood can be installed without needing to vent outside. Recirculation happens through filters to help keep the air fresh.
- Help regulate the flow of air through the chimney with the included 6" round damper (part number W10446915).
- Extend chimney height for ceilings from 8'4" to 12'4" with the Optional Chimney Extension Kit. See installation instructions for details. Optional Chimney Extension Kit sold separately. Part number EXTKIT10ES.
Product Description
Get the right amount of ventilation for every meal using a 3-speed range hood with filter to trap unwanted grease, while a convertible design allows for installation without venting outside.
Rebates
Specification
Accessory Relationships | |
Accessory Relationships | Yes |
Certifications|Energy Star® Certified | |
Certifications|Energy Star® Certified | No |
Certifications|Kosher Consumer Friendly | |
Certifications|Kosher Consumer Friendly | No |
Certifications|Prop 65 | |
Certifications|Prop 65 | Standard |
Certifications|UL | |
Certifications|UL | Yes |
Controls|Control Location | |
Controls|Control Location | Front |
Controls|Control Type | |
Controls|Control Type | Push Button |
Description|Hood Type | |
Description|Hood Type | Wall-Mount Canopy |
Description|Size (in.) | |
Description|Size (in.) | 36 |
Dimensions | |
Carton Depth | 39 5/16 in |
Carton Height | 25 1/4 in |
Carton Width | 17 3/8 in |
Depth | 19 11/16 in |
Width | 36 in |
Gross Weight | 64 in |
Maximum Height | 45 5/16 in |
Minimum Height | 27 5/16 in |
Net Weight | 46.4 in |
Dimensions|Carton Depth(IN,inches) | |
Dimensions|Carton Depth(IN,inches) | 39.3125 |
Dimensions|Carton Height(IN,inches) | |
Dimensions|Carton Height(IN,inches) | 25.2500 |
Dimensions|Carton Width(IN,inches) | |
Dimensions|Carton Width(IN,inches) | 17.3750 |
Dimensions|Depth(IN,inches) | |
Dimensions|Depth(IN,inches) | 19.6875 |
Dimensions|Gross Weight(LB,pounds) | |
Dimensions|Gross Weight(LB,pounds) | 64 |
Dimensions|Maximum Height(IN,inches) | |
Dimensions|Maximum Height(IN,inches) | 45.3125 |
Dimensions|Minimum Height(IN,inches) | |
Dimensions|Minimum Height(IN,inches) | 27.3125 |
Dimensions|Net Weight(LB,pounds) | |
Dimensions|Net Weight(LB,pounds) | 46 |
Dimensions|Width(IN,inches) | |
Dimensions|Width(IN,inches) | 36.0000 |
Electrical|Amps | |
Electrical|Amps | 15 |
Electrical|Hz | |
Electrical|Hz | 60 |
Electrical|Power Cord Included | |
Electrical|Power Cord Included | No |
Electrical|Volts | |
Electrical|Volts | 120 |
Electrical|Watts | |
Electrical|Watts | 320 |
Features|BTU Threshold | |
Features|BTU Threshold | 44.5 K |
Features|Damper Included | |
Features|Damper Included | Yes |
Features|Lighting Control Type | |
Features|Lighting Control Type | Push Button |
Features|Night Light | |
Features|Night Light | No |
Features|Night Light Type | |
Features|Night Light Type | N/A |
Features|Number of Task Light Settings | |
Features|Number of Task Light Settings | 1 |
Features|Task Light Type | |
Features|Task Light Type | LED |
Features|Task Lighting | |
Features|Task Lighting | Yes |
Ventilation System| HVI (CFM HS Vertical) | |
Ventilation System| HVI (CFM HS Vertical) | 320 |
Ventilation System|Auto Function | |
Ventilation System|Auto Function | No |
Ventilation System|Blower Type | |
Ventilation System|Blower Type | Centrifugal |
Ventilation System|Duct Direction | |
Ventilation System|Duct Direction | Vertical |
Ventilation System|Duct Length | |
Ventilation System|Duct Length | 35.000 |
Ventilation System|Duct Outlet Size (in.) | |
Ventilation System|Duct Outlet Size (in.) | 6 |
Ventilation System|Duct Type | |
Ventilation System|Duct Type | Round |
Ventilation System|Exhaust Vent Location | |
Ventilation System|Exhaust Vent Location | Top |
Ventilation System|Filters | |
Ventilation System|Filters | Grease Filters |
Ventilation System|Maximum Motor Exhaust Rating Cubic Feet per Minute (CFM) | |
Ventilation System|Maximum Motor Exhaust Rating Cubic Feet per Minute (CFM) | 400 |
Ventilation System|Number of Vent Speeds | |
Ventilation System|Number of Vent Speeds | 3 |
Ventilation System|Vent Material | |
Ventilation System|Vent Material | Steel |
Ventilation System|Venting | |
Ventilation System|Venting | Exterior or Recirculating |
Documentation
From the Manufacturer
Warranty
Delivery
Disclosures
Proposition 65 Warning for California Residents
Cancer and Reproductive Harm - P65Warnings.ca.gov
Get the right amount of ventilation for every meal using a 3-speed range hood with filter to trap unwanted grease, while a convertible design allows for installation without venting outside.
Features
3-speed, 300 CFM motor class (Performance varies based on installation. Resources available at aham.org.)
- Three fan speeds provide the right amount of ventilation for every meal you prepare.
- Bright, long-lasting LED task lighting makes it easy to see what you're cooking.
- Help trap unwanted grease and remove odors with a filter that unlatches from the hood so you can wash it with soap and water at the sink.
- A convertible design allows for installation that can be vented externally or internally. When internal venting, recirculation passes the air through charcoal filters (sold separately) to trap grease and odors before pushing the air back into the home.
- This hood is equipped to handle the high heat and cooking power of cooktops up to 44.5K BTUs.
- This hood can be installed without needing to vent outside. Recirculation happens through filters to help keep the air fresh.
- Help regulate the flow of air through the chimney with the included 6" round damper (part number W10446915).
- Extend chimney height for ceilings from 8'4" to 12'4" with the Optional Chimney Extension Kit. See installation instructions for details. Optional Chimney Extension Kit sold separately. Part number EXTKIT10ES.
